Features
- Achieves a pulling speed of over 1.2 meters/second, compared to the conventional speed of under 1 meter/second.
- Seamless cutting at billet joints, with an intelligent saw control system that automatically adjusts the saw speed based on the aluminum extrusion speed results in higher yield rates.
- Crescent-shaped clamps ensure smooth pulling and cutting, preventing deformation and eliminating vibration marks on the aluminum profile surface.
- Powered by Siemens servo motors, utilizing servo motor encoder positioning technology, eliminating traditional proximity switches and sensors to reduce fault rates and enhance stability.
- All structural joints use gear and rack drives, offering long service life and zero-fault operation.
- Enables remote control and maintenance for added convenience.
- The only system in the industry to utilize imported Siemens Wi-Fi communication technology.
- Tracks made with square tube supports, cold-drawn steel, and elevator rails ensure precision and durability. Gear hardness is rated at 45°, and rack hardness at 40°.
- Automated sampling at the initial, middle, and final stages of pulling, with the system completing the sampling process autonomously.
- Uses imported SKF and NSK bearings for reliability and longevity.
